Home > Products > Sole > Shoe Sole Injection Molding Machines Z/2080

Shoe Sole Injection Molding Machines Z/2080

Shoe Sole Injection Molding Machines Z/2080

    Payment Type: L/C,T/T
    Terms of Trade: FOB,CFR,CIF
    Min. Order: 1 Set/Sets
    Delivery Time: 40 Days
    Packaging: Wooden boxs, Pallet
    Brand: WELLISH
    Transportation: Ocean,Land
    Place of Origin: NINGBO
    HS Code: 8477101090
    Port: NINGBO PORT,SHANGHAI PORT

Basic Info

Model No.: Z/2080

Product Description

NINGBO BEILUN ALLWAY MACHIENRY CO., LTD. was founded in 1998. Now has 20 years of production experience.

Z Series main features:

1.According to product demand , easy to customize opening stroke

2.Mold opening & clamoing with agility and stability , which has impoved cycle time

3.Increase the service life and reduce maintenance cost

4.With strong stiffness of frame platen , which can reduce the floor area


Z series technical parameters

INTERNATIONAL CLASS NO.



2080/24080
SPECIFICATION

Z/2080
Screw type

A
B
C
Injection Unit
Screw diameter
mm
150
160
170
Screw L/D ratio
L/D
23.5
22
20.7
Shot volume (theoretical)
CM³
13887
15800
17837
Injection weight (PS)
g
12637
14378
16232
Injection rate
g/s
1315
1496
1689
Injection pressure
Mpa
173
152
135
Screw speed
rpm
75
Clamping Unit
Clamping force
KN
20800
Space between tie-bars
mm
1800*1600
Max .mould height
mm
1800
Min . mould height
mm
800
Ejector stroke
mm
450
Ejector force
KN
450
Max daylight
mm
3600
Mould opening stroke
mm
2800/1800
Max.mold weight
t
50
Other
Pump max . pressure
Mpa
21
Pump motor power (servo)
KW
45+55+55+11
Heating power
KW
114
Numbers of heating area
Segment
9+1
Machine dimension (L*W*H)
M
13.5*4.3*4.9
Oiltank cubage
L
2600
Machine weight
TON
115




ALLWAY , Always on the way!



 NINGBO BEILUN ALLWAY MACHINERY CO.,LTD is located in Hailong Industry Park Development Zone (Beilun),Ningbo,China,which is attached to Hailong Group.Our company is found in 1995 ,cover dozens of more than 80,000m2 production base and has a professional technology engineer team who has been long engaged in design and manufacturing each type of machine flexibly.Besides,our company owns advanced CAM manufacturing and production facilities,and the whole process from Material,parts,assembly and testing instruments is in accordance with ISO quality guarantee system.The engineering technology center has achieved modern management of CAE simulation optimization design.PDM design process management and ERP operation system. Our company has got both 1st level energy conservation certification,ISO 9001-2008 certifacation & CE authentication for Die casting machine(Hot chamber 30-200t,Cold chamber 140-2000t,MG 140-2000t).The OEM base of some JAPAN,ITALY,SPAIN brand machines .Besides We have cooperation with European partner,to design our machine with innovation and perfection together,so as to bring more our European style machines to the market. Our company has got JAPAN JIS 1class precision,ISO 9001-2008 certifacation & CE authentication for Press machine(15-1600Tons).The OEM base of some JAPAN,ITALY,SPAIN brand machines .Besides We have cooperation with European partner,to design our machine with innovation and perfection together,so as to bring more our [AOMATE"style machines around the world. Our company has got both 1st level energy conservation certification & CE authentication for Injection molding machine(UJ 90-3000T,PVC 150-680T,PET150-680T).We have cooperation with European partners,to design our machine with innovation and perfection together,so as to bring our European style machine to the market. ALLWAY --- always on the way with you !
